Specifications:
Longitudinal Table speeds: 3" to 150′
Hydraulic table travel, longitudinal (maximum): 35 1/2"
Hydraulic table travel transverse (maximum): 15 3/4"
Working surface of table: 14" X 24"
Standard wheel size: 14" X 11/2" X 5"
Vertical movement of wheel head: 19"
Maximum distance from wheel to table under 14" wheel: 18"
Distance center of spindle to bottom of spindle housing: 3"
Spindle speeds: 1750 & 2100 RPM
Hydraulic Pump motor 3 H.P., 1140 RPM 220 / 440 Volts AC , 10 / 5 Amps
Spindle Drive Motor: 7 1/2 H.P. 1750 RPM 220 / 440 Volts AC , 21 / 10.5 Amps
Currently on 460 VAC
Dimensions:
W: 76" X D: 70" X H: 92"’
10,000 Lbs
Preliminary Specifications Subject to Verification
