Specifications:
Max Surface Grind 10" x 20"
Height Travel From Table Top to Center of Spindle: 19 1/2"
Variable Table Speed, Hydraulic 16′ to 80′ FPM
Maximum Table Travel: 20 1/2"
Automatic Cross Feed Increment 0" to 1"
Maximum Cross Trael 11"
Maximum Crossfeed Travel 11"
Downfeed Handwheel Per Graduation 0.0005"
Per Revolution 0.1"
Crossfeed Handwheel Per Grduation 0.001"
Pre Revolution 0.2"
Automatic Incremental Downfeed 0.001" to .0001"
Spindle Motor 2 H.P.
Standard Grinding Wheel 8"D x 3/4" x 1-1/4"
Maximum Table Load Capacity Including Chuck 700Lbs
Equipped With:
Automatic Incremental Downfeed (Surface and Plunge)
Hydraulic Power Longitudinal Feed
Power Crossfeed
Turcite-B on the Longitudinal Ways (Low Friction & Wear)
8" x 18" Manual Chuck
Combination Coolant System & Dust Collector
Over The Wheel Dresser
Auto Lube System
External Hydraulic System
2 HP 3/60/230-460 Volt External Hydraulic Pump Motor Tank
2 HP 3/60/230-460 Volt Spindle Motor
Presently Wired on 230 VAC
Machine Dimensions:
W: 66" x D: 61" x H: 74"
Hdraulic Unti: W: 24" x D: 27" x H: 38"
Vaccum System W: 18" x D: 37" x H: 38"
Skid Dimensions: W: 88" x D: 68"
Aprox Weight 3,600
Preliminary Specifications Subject to Verification
